– Generate the addressing scheme for your IP network.

If you are setting up a connection to a corporate network, you and the network administrator must generate and share the following information for the WAN interfaces of the routers:.

– DNS server IP address and default gateways – PPP password to access your Internet service provider (ISP) account – PPP authentication type: Challenge Handshake Authentication Protocol (CHAP) or Password Authentication Protocol (PAP) – Point-to-Point Protocol (PPP) client name that is assigned as your login name

If you are setting up an Internet connection, gather the following information:.

You need to gather some or all of the following information, depending on your planned network scenario, prior to configuring your network

Use the show running-config command to view the initial configuration, as shown in Example 1-1.Įxample 1-1Ĝisco 851 Default Configuration on Startup All of the LAN and WAN interfaces have been created, console and VTY ports are configured, and the inside interface for Network Address Translation has been assigned. When you first boot up your Cisco router, some basic configuration has already been performed. It also describes the default configuration on startup.

This chapter provides procedures for configuring the basic parameters of your Cisco router, including global parameter settings, routing protocols, interfaces, and command-line access. Configure the Fast Ethernet WAN InterfaceĬonfiguring Command-Line Access to the Router
